BM Line 35 - Backes&Müller

BM Line 35

With its emphasis on a sleek design and a baffle width of just 20 centimeters, the B&M BMLine 35 integrates harmoniously into any living environment. Yet, its elegant appearance is only the beginning. The BMLine 35 effortlessly masters even particularly large and acoustically challenging rooms: Our unique, patented B&M Cylinder Wave Radiator specifically eliminates the often sub-optimal acoustic properties of the listening room while simultaneously providing an exceptionally wide sweet spot. A perfect soundstage and outstanding audio quality are guaranteed by our proprietary FIRTEC processor, sensor control, and integrated room calibration.

The BMLine 35 – A One-of-a-Kind Masterpiece

Exquisite paint finishes, elegant metal surrounds for the drivers, and bespoke finishes allow you to create a truly unique piece that perfectly complements your home interior.

Let’s discuss your personal requirements — we look forward to hearing your ideas.

eng

Sie können unseren Produktkatalog ganz bequem per Post bestellen. Füllen Sie dazu einfach das Anfrageformular aus. Nach Eingang Ihrer Anfrage senden wir Ihnen den Katalog schnellstmöglich zu.

Technical Data

Find the most important technical data and specifications for this product here.  All information serves as an overview of the central performance characteristics.

Side panels 4x
DMC2.0™ servo-controlled 12“ high-performance bass drivers
Front 10 x
6“ carbon-fiber drivers with FIRTEC™ equalization
Front 1 x
Fraunhofer cylindrical-wave radiator (1“)
Amplifier power
< 3000 W (RMS)
Frequency range
22 – 24,000 Hz (+/-3 dB), crossover at 80 Hz and 800 Hz
Input sensitivity
up to 20 dBu
AD/DA converter
24-bit sigma-delta D/A converter technology up to 192 kHz
Analog IN, OUT
balanced XLR
Digital IN
B&M Easylink, digital AES input for direct connection to a digital source
Subwoofer-Out
switchable subwoofer out with full DSP processing for connecting a BMLine subwoofer
Processing
FPGA-based DSP and microcontroller design, developed in-house
Dimensions W x H x D:
20 x 173 x 48 cm, 100 kg
Remotable
with optional B&M PPG
